Applications

• Mines, Crushers, Coal Ore & Slurries
• Domestic and community water supply
• Irrigation in horticulture & agriculture
• Air conditioning and refrigeration System
• Industrial service water supply schemes
• Firefighting system

Technical Specification

• Power Rating: 7.5HP to 20HP (5.5KW to 15KW)
• Head: Up to 50 Meters
• Flow: Up to 94 m³/h
• Voltage: 380 – 420 V
• Frequency: 50 HZ
• Protection: IP 55
• Insulation: F
• Speed: 2900 rpm

Material of Construction

• Casing: Cast Iron
• Impeller: Cast Iron
• Motor’s Casing: Cast Iron
• Shaft: Steel
• Type of Sealing: Gland Packing

Features

• Dynamically balanced rotating parts ensure minimum vibrations.
• Replaceable wearing parts and hence longer life.
• Non overloading power characteristics
• Easy maintainable designs
• High efficiency and energy saving design
